Product Overview

  • Makes up to 293 lb. of half dice ice per day; stores up to 119 lb.
  • Removable bin allows for easy access to clean refrigeration components
  • Front air intake and exhaust
  • Easy-access door slides up and out of the way
  • 120V
UPC Code:UYF0310W-161B

Manitowoc Ice UYF0310W-161B Specs

Quantity
1/Each
Shipping Weight
200 lb.
Width
30 Inches
Depth
28 1/2 Inches
Height
38 1/2 Inches
Voltage
120 Volts
24 Hour Ice Yield
293 Pounds
Bin Storage Capacity
119 lb.
Condenser Type
Water Cooled
Features
NSF Listed
Ice Type
Half Size Cubes
Installation Type
Undercounter
Plug Type
NEMA 5-15P
Power Usage
5.5 kWh per 100 lbs.
Type
Ice Machines
Water Inlet Size
3/8 Inches

Manitowoc Ice UYF0310W-161B Details

Make and store ice in one compact machine with this Manitowoc UYF0310W NEO undercounter ice machine. This water cooled ice machine combines impressive ice production, user-friendly controls, and simple maintenance in a space-saving undercounter package! Ideal for making ice in small volume applications or as a supplement to a larger ice machine, this unit can produce up to 293 lb. of half dice cubes per day while boasting an ample 119 lb. bin. A push pad control and indicator panel boasts universally recognizable display icons that show you when the power's on, the bin's full, service is needed, and when there's a clean cycle in progress. There's even a "delay" button that halts ice production for 4, 12, or 24 hours, making it perfect for operations that are only open for portions of a day! The buttons are brightly illuminated by LED lights and placed on the slanted bin front so that you can easily press and view them without having to bend over.

This ice machine features an easy-access door that slides up and out of the way, giving you a clear path to the ice for simple filling of pitchers, glasses, and even transport buckets. It also conveniently includes an ergonomic scoop with a comfort grip handle, along with a holder that can be mounted on either side of the machine for easy storage and access. The machine's air filter is designed for simple, tool-free removal for quick access during routine cleaning and maintenance, while the bin can be easily removed for full access to the machine's interior components during more thorough cleaning and maintenance. A 120V electrical connection is required for operation.

Overall Dimensions:
Width: 30"
Depth: 28 1/2"
Height: 38 1/2"

This Item Ships via Common Carrier. For more information and tips to help your delivery go smoothly, click here.

Attention CA Residents:
  • NSF Listed

    NSF Listed

    This item has been certified by NSF International to meet applicable product standards on public safety, health, and / or the environment.

  • UL Listed, US & Canada

    UL Listed, US & Canada

    This product has been certified by the Underwriters Laboratories (UL) to meet applicable safety standards required for use in the United States and Canada.

  • CE Listed

    CE Listed

    This product complies with the standards imposed by Conformance European (CE).

  • ARI / AHRI

    ARI / AHRI

    This certification is awarded by the Air-Conditioning, Heating, and Refrigeration Institute to denote products of exceptional performance.

  • 3/8" Water Connection

    3/8" Water Connection

    This unit comes with a 3/8" water connection for water supply.

  • 5-15P

    5-15P

    This unit comes with a NEMA 5-15P plug.

Questions & Answers

Looking For Specific Info?

Get quick answers to product questions with our AI-powered search.

Ask about this product

Frequently Asked Questions From Customers

How can I figure out the total daily water consumption of my water cooled ice maker?
In order to figure out the total daily water consumption you must take into consideration both condenser cooling water as well as potable ice making water. The equation is as follows:

(Potable Water + Condensor Water) x (lb. of ice per day / 100)

Example: (12 gal + 124 gal) x (400 lb / 100) = 544 gallons per 24 hours

Need Parts & Accessories?

Show replacement parts and accessories for Manitowoc Ice UYF0310W-161B today!

Resources and Downloads for
Manitowoc Ice UYF0310W-161B

A PDF viewer is required to view this product's information. Download Adobe Acrobat software

Warranty Info

RESIDENTIAL USERS: Vendor assumes no liability for parts or labor coverage for component failure or other damages resulting from installation in non-commercial or residential applications. Your warranty will be voided if installed in non-commercial or residential applications. PLEASE NOTE: Parts carry a 90 day limited warranty.

Equivalent Items

Manitowoc Ice UY-0310W (Formerly)
